FOIF RTS102R5 types of total station memory 120000 points,support SD card total station survey instrument

FOB Reference Price:Get Latest Price
US $1,300-2,300 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanghai, China (Mainland)
Brand Name:
FOIF
Model Number:
RTS102R5
Product name:
FOIF RTS102R5 types of total station
Magnification:
30X
Image:
Erect
Field of view:
1°30'
Shortest focus distance:
1.0m
CPU:
32Bit
Battery:
3400mAh Li-ion Rechargeable
Output voltage:
7.4 VDC
Charger:
FDJ6-F1(100V/240V)
Dimensions (W X D X H ):
175 X 178 X 340mm
Supply Ability
Supply Ability:
1000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Packed in the carton
Port
Shannghai,China
Lead Time :
2-3 working days after payment confirmed

FOIF RTS102R5 types of total station memory 120000 points,support SD card total station survey instrument

Product Description



Key features

♥ Measuring distance :500m



♥ RTS100R3 EDM can be upgraded to RTS100R5 EDM(Factory Optional)



♥ Bluetooth cable-free connection(Factory Optional)



♥ 120000 point and 40 Jobs can be saved



♥ Can be operated with a data collector,FOIF FieldGenius or other third party software is available



♥ IP66 environmental protection



♥ Alphanumeric keyboard





RTS100R connect to data controller though Bluetooth or RS-232C







Product show:



SPECIFICATIONS:



Technical data
Model RTS102R5
Telescope
Length156mm
ImageErect
Objective apertureφ45mm
Magnification30X
Field of view1°30'
Shortest focus distance1.0m
Reticle illuminationYes-9 level
Angle measurement
Reading systemAbsolute encoder
Angle unit360°/400gon/6400mil,selectable
Display resolution 1"/5"/10"(or 0.2mgon/1mgon/2mgon)
Accuracy2"/5"
Distance measurement
Laser class(IEC60525-1)
ReflectorlessClass 3R
Reflective sheet/RP60Class 3R
PrismClass 1
Measurement range (Good condition)*1
Reflectorless*2
R31 to 300m
R51 to 500m
Reflective sheet/RP601 to 800m
Single prism(Class 1)1 to 3000m
Single prism(Class 3R)1 to 5000m
Accuracy
Prism2mm+2ppm
Reflective sheet/RP603mm+2ppm
Reflectorless
R33mm+2ppm
R53mm+2ppm
Measuring timeInitial :2s
Prismtyp.1.0-1.5s
Reflective sheet/RP60typ.1.5s
Reflectorlesstyp.1.5-5s, max. 20s
Display resolution (m/inch selectable)0.2mm/1mm
Temperature input range-40℃ to +60℃(1℃ steps)
Pressure input range500hPa to 1500hPa (1hPa steps)
Prism constant correction-99.9mm to +99.9mm
CompensatorDual-axis
Range±3‘
Setting accuracy1"
Plate level vial30"/2mm
Circular level vial8'/2mm
Laser plumment(Standard)
Accuracy±1mm/1.5m
Laser classClass2/IEC60825-1
Laser spot brightnessAdjustable
Laser wave lenght635nm
Optical plumment(Factory Optional)
Accuracy±0.8mm/1.5m
ImageErect
Magnification/Field of view3X / 4°
Focus range0.5m to ∞
Power
Battery3400mAh Li-ion Rechargeable
Output voltage7.4 VDC
Continuous operation time          Approx.26 hours (at +20℃)
(Single distance measurement every 30 seconds)
ChargerFDJ6-F1(100V/240V)
Charging time (at +20℃)Approx.4hours
Application programs
Data collection /Stake out/Resection/REM/MLM/Road
AREA/Point to line/Z coordinate/OFFset/Arc staking out)
Others
Display Double LCD displays, 6lines X20
characters(96 x 160 dots
Electronic level in displayYes
CPU32Bit
Memory120000 points,support SD card (max.16G)
KeyboardAlphanumerical key board, both sides
Weight(including batteries)5.1kg
Dimensions (W X D X H )175 X 178 X 340mm
Operating temperature-20℃ to + 50 ℃
Storage temperature-40℃ to + 70 ℃
InterfaceUSB/RS-232C/Bluetooth(Factory Optional)
Water and dust protectionIP66 (IEC60529)
Date transfer softwareFOIF Geomatics Office (FGO)
Data collectorF52G or PS236, fully rugged PDA(Optional)
*1Good condition: no haze,visibility about 40km,no heat shimmer,breeze
*2Reflector :White side of Kodak Gray Card with 90% reflective
