Setl brand SJDJ-J02 laser digital theodolite prices

FOB Reference Price:Get Latest Price
US $400-500 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
China (Mainland)
Brand Name:
Selt
Model Number:
SJDJ-J02
Angle method:
Absolute encoder
Plummet:
Built-in laser plummet
laser direction:
with laser direction
Water proof:
IP6 class
Display:
2 sides, large LCD
Angle unit:
DEG or GON
Discreen illumination:
Yes
Auto power off:
Yes
Selt SJDJ-J02:
theodolite prices
Supply Ability
Supply Ability:
100 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Setl brand SJDJ-J02 laser digital theodolite prices :
1 piece packed in 1 carton
Size(L*W*H):42*30*40cm
Weight:6KG
Port
Shanghai
Lead Time :
3 working days

Setl brand SJDJ-J02 laser digital theodolite prices



Company profile:




    TIANJIN SETL SURVEY EQUIPMENT CO., LTD  was founded in 1991, is one of the biggest manufacturer of surveying instruments and accessories in China. Our main products are automatic levels, theodolites, total station and surveying accessories which are sold to Europe, America, Japan and so on more than 40 countries and regions.





Setl brand SJDJ-J02 laser digital theodolite prices :

  • Visible laser direction
  • Measuring angle system is absolute encoder and can enter into status of measuring without initial setting.
  • Laser can be observed by eyepiece directly.
  • Water proof is IP6
  • Built-in laser plummet can be interchanged
  • Large LCD screen with lock.

Technical Data:



Technical parameter

SJDJ-J02

Telescopic


Erect

Magnification

30×

Clear Objective aperture

45mm

Angle of field of view

1°30

Shortest stadia

1.35m

Stadia multiplying constant

100

Stadia additive constant

0

Resolving power

3

Measure angle system

Method of measuring angle

Absolute encoder

Minimum reading

1

Method of detecting

H:two sides V:one side

Accuracy of measuring angle

2

Angle unit

DEG  or GON

Display

LCD two sides

Compensator

Tilt sensor

plumb compensation automatically

Range of compensator

±3

Laser plummet

Laser power

1mW

Facular diameter

2mm

Alignment accuracy

1.5mm(1.5m height of theodolite )

Bubble

Accuracy of plate bubble

30/2mm

Accuracy of circular bubble

8/2mm

Laser pipe

Wavelength

635nm

Power

5mW

Largest measuring distance

180m(under sunshade daytime)

Central facular diameter

3mm/00m

Non-coaxial error between laser axis  and collimation axis

10

Power Supply

Battery

Dry battery or  charged nickel-hydrogen battery

Power Voltage

4.8V

Continuous operating time

36h(without laser)

Others

Weight of theodolite

4.6kg

Dimensions

164×154×340mm

Working environment temperature

-20°C~+50°C



 Setl SJDJ-J02 theodolite (8).jpgSetl SJDJ-J02 theodolite (10).jpgSetl SJDJ-J02 theodolite (7).jpgSetl SJDJ-J02 theodolite (9).jpgSetl SJDJ-J02 theodolite (11).jpgSetl SJDJ-J02 theodolite (2).jpg
