Kolida ET-02 Digital theodolite

FOB Reference Price:Get Latest Price
US $480-500 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guizhou, China (Mainland)
Brand Name:
Kolida
Model Number:
KT-02
Angle measurement:
Absolute Encoding
Laser dot:
Visible laser dot from the eyepiece.
Accuracy:
2"/5" optional
Minimum reading:
1"/5" optional
Compensator:
Liquid-electronic detection
Display:
2 sides, large LCD
Plummet:
optical plummet/Laser plummet optional
Data port:
RS232
Type:
Digital theodolite
Supply Ability
Supply Ability:
100 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Kolia ET-02 Digital theodolite packing mode:
Inner foam pad + Engineering plastic carrying case + Outer foam pad + Double paper carton
Size(L*W*H):48*26*40cm
Weight: 6KG
Port
Shanghai
Lead Time :
3 working days

Specifications

1.Full featured digital theodolite for general construction
2.Annual sale reaches 16,000 pcs, NO.1 in China
3.Dual LCD screen

 Kolida ET-02 digital theodoltie

        Kolida Digital Theodolite is a rugged, cost-effective theodolite. This affordable and easy-to-use instruement is designed to give accurate angle measurements in general construction applications.



Kolida company introduction:


KOLIDA, a large group corporation which specializes in designing, manufacturing, distributing, and servicing of surveying instruments, commits itself to supplying advanced, high-quality and good-priced surveying instruments all the time.





 Kolida ET-02 digital theodoltie  features :



1. Annual sale reaches 16,000 pcs, NO.1 in China!

2. Absolute encoding disc, angle data retains after sudden shut-off

3. Dual LCD big screen

4. Work 10 hours by 1 batter

5. Full featured digital theodolite for general construction application

6. 2" angular accuracy - accurate enough for any construction job

7. Back-lit LCD and telescope reticle, 6 keys totally, built-in illumination



Specification :

Model

KT-02/02L

KT-05/05L

Telescope

Magnification

30x

Length

157mm

Minimum focus

1.4m

Aperture

45mm

Resolving power

30"

Field of view

1°30’


Erect

Multiplication constant

100

Stadia constant

0

Angle measurement

Measuring mode

Absolute Encoding

Min.Reading

1"/5" (selectable )

Angular accuracy

2"

5”

Diameter of circle

79mm

Detection method

Horizontal angle

Dual

Vertical angle

Dual

Single

Laser Indicator

Valid distance

120m

Display

Type

2 sides, LCD Display

DATA I/O

Interface

RS-232C

Auto Vertical Compensator

System

Liquid-electricd etection 4'

Accuracy

Liquid-electricd etection:1"

Optical plummet


Erect

Magnification

3x

Field of view

Focusing rang

0.5m to infinity

Level vial sensitivity

Plate Vial

30” per 2mm

Circular Vial

8’ per 2mm

Physical Characteristics

Operating Voltage

4-6VDC

Battery

Rechargeable Ni-MH battery/AA battery

Operating time

10 hours

Operating Temperature

-20°C to +50°C

Dimension

165mm x 157mm x 318mm

Weight

4.3kg

Water and Dust Proof

IP55
